AI-Powered Playwright Hybrid E2E Framework

A production-ready, AI-powered test automation framework that unifies UI and API testing with intelligent workflows.

Inside you'll find an MCP-integrated Playwright stack that blends UI and API automation with WebdriverIO/Appium mobile coverage—optimized for fast feedback, high reusability, and clean abstractions.

Why This Framework?

• Fast Onboarding - Get productive in minutes with AI-assisted test authoring
• Reliable - API-backed setup eliminates flaky tests and data dependencies
• Maintainable - SOLID principles and Page Object Model keep code clean
• Observable - Built-in reporting, visual regression, and CI/CD integration
• AI-Native - Natural language commands accelerate test creation and debugging

Highlights

• Fixture-driven architecture injects fully configured pages and API clients into every test.
• SOLID-aligned Page Object Model keeps selectors and actions encapsulated while leaving assertions in the test layer.
• API-backed setup & verification enables reliable test data management and faster feedback loops.
• Cross-device coverage for desktop Chrome, iOS emulation, and LambdaTest mobile runs.
• Visual regression support with baseline snapshots per device.
• AI-assisted authoring powered by the Playwright MCP server, enabling natural language-driven automation and live DOM scanning without additional npm scripts.

Architecture at a Glance

• Fixtures: fixtures/automation-fixtures.ts wires Playwright pages, API clients, and auth helpers into the test context.
• Page Objects: tests/playwright/pages/* encapsulate locators and interactions for each surface (login, notes dashboard, profile, etc.).
• API Clients: api/clients/* expose typed helpers for REST endpoints via the ApiClientFactory.
• Authentication: auth/authSetups/global-setup.ts prepares storage states so UI tests start authenticated when required.
• Configuration: configs/playwright.config.ts centralizes projects, reporters, and global behaviors; separate WDIO configs power mobile emulation.

Repository Layout

├── api/                         # API clients, endpoints, and data models
│   ├── clients/                 # Base client + domain-specific clients (health, notes)
│   ├── endpoints/               # Endpoint builders referenced by the clients
│   ├── models/                  # Shared request/response interfaces
│   └── utils/                   # Helper utilities (e.g., note lookups)
├── auth/                        # Authentication manager, global setup, storage states
├── configs/                     # Playwright + WDIO configuration files
├── fixtures/                    # Playwright fixtures that inject pages, clients, and helpers
├── reporters/                   # Post-run integrations (e.g., Microsoft Teams notifications)
├── tests/
│   ├── playwright/
│   │   ├── features/            # Playwright test specs orchestrating POM flows
│   │   └── pages/               # Page Object Model classes + PageFactory
│   └── appium/                  # Mobile UI specs and page objects for WebdriverIO
├── visual-snapshots/            # Baseline images per project for visual comparisons
├── playwright-report/           # Last generated Playwright HTML report (gitignored in CI)
├── test-results/                # Aggregated artifacts from previous runs
├── package.json                 # npm scripts, dependencies, toolchain versions
├── tsconfig.json                # TypeScript compiler configuration
└── README.md                    # You are here

Prerequisites

• Node.js 18 or later
• npm (bundled with Node.js)
• Visual Studio Code with the Playwright VS Code extension for debugger-friendly runs
• Access credentials for the ExpandTesting Notes app (see Environment configuration)

Optional but recommended:

• GitHub Copilot for faster authoring
• Chrome DevTools knowledge for live DOM inspection via the "open chrome" workflow

Environment Configuration

Create a .env file in the project root (or export the variables in your shell) with the following keys:

Variable	Description
MAIN_USERNAME	Primary account email used for authenticated UI flows
MAIN_PASSWORD	Password for MAIN_USERNAME
API_BASE_URL	Base URL for REST requests (e.g., https://practice.expandtesting.com/notes/api)
UI_BASE_URL	Base URL for UI navigation (default https://practice.expandtesting.com/notes/app)

The npm scripts rely on cross-env to load these variables (see package.json).

Quick Start

Get up and running in under 2 minutes, then pair it with the MCP-powered "open chrome" flow to lock selectors in minutes:

# 1. Clone and install
git clone https://github.com/x-typo/playwright-mcp-ai-testing.git
cd playwright-mcp-ai-testing
npm install

# 2. Install Playwright browsers (first-time only)
npx playwright install

# 3. Create .env file with your credentials
# See "Environment Configuration" section below

# 4. Run your first test
npm run chrome-debug -- --grep "@smoke"

Success! You should see the Playwright debugger open and tests running.

AI Workflow Requirements

To leverage the AI assistant for DOM inspection or natural language automation flows:

• Install the Playwright MCP server and follow the repo instructions to configure credentials and start the service.
• Connect via an MCP-aware client—GitHub Copilot Chat (Command Palette → “GitHub Copilot: Manage MCP Servers”), Claude Code, Codex, or the MCP CLI (npx @playwright/mcp@latest)—so the agent can attach to the server.
• Use the "open chrome" instruction with the AI agent to launch a pre-authenticated browser session; the MCP server handles DOM scanning directly.
• Continue to rely on standard scripts such as npm run chrome-debug or npm run chrome-ui for verification runs.

Getting Started

1. Install dependencies

   npm install

2. Install Playwright browsers (first-time setup only)

   npx playwright install

3. Verify credentials by running a quick smoke test:

   npm run chrome-debug -- --grep "@smoke"

   The debug UI opens Playwright's runner so you can watch the flow and capture traces if needed.

Running Tests

Scenario	Command
Interactive desktop debugging (recommended)	npm run chrome-debug -- --grep "Scenario Name"
Interactive iOS emulation	npm run ios-debug -- --grep "Scenario Name"
Headless desktop smoke/regression	npm run chrome-ui -- --grep "@smoke"
Visual regression (desktop / iOS)	npm run chrome-visual / npm run ios-visual
Playwright Test UI mode	npm run ui-mode
Show latest HTML report	npm run report
Generate selectors with codegen	npm run codegen-desktop / npm run codegen-mobile

Tip: When authoring or fixing selectors, launch the pre-authenticated browser by requesting "open chrome" from the AI agent. It navigates to the login page and signs in automatically using the configured credentials.

Test Tags & Filters

• Apply tags via test.describe.configure({ mode: "parallel", retries: 0 }, { tag: ["@smoke"] }); in each spec.
• Filter runs using Playwright's --grep / --grep-invert flags (already wired through npm scripts).
• Reserve @visual for scenarios that compare snapshots stored in visual-snapshots/.

Authenticated vs Guest Sessions

• Use test.use(asUser("main")) (via fixtures) when a test requires the pre-seeded storage state.
• Use test.use(asUser("guest")) for login or registration flows that must start unauthenticated.

API & UI Collaboration

• API Clients: Access the notesClient, healthClient, etc., directly from fixtures inside your tests for data setup or verification.
• Data Helpers: Utilities such as getNoteIdByTitle streamline cleanup; add new helpers under api/utils/.
• Assertions: Keep all assertions in specs—page objects should expose only behaviors and locators.

Reporting & CI

• Local reports: npm run report renders the last Playwright HTML report; WDIO runs output to allure-results/ (if configured) and Teams reporters.
• CI compatibility: The config supports GitHub Actions and Jenkins. JUnit XML artifacts are generated automatically under desktop-junit-reports/ for pipeline consumption.
• Visual diffs: Baselines live in visual-snapshots/; adjust thresholds via expect().toMatchSnapshot options in tests.

Extending the Framework

• New Page: Extend BasePage, register it inside PageFactory, and expose it through fixtures.
• New API Client: Extend BaseApiClient, add an entry inside ApiClientFactory, and inject it through the appropriate fixture.
• New Environment: Duplicate/update entries in configs/playwright.config.ts or WDIO configs to add more device/browser coverage.
• Shared Utilities: Place XHR interceptors, data builders, and loggers in api/utils/ or fixtures/ to keep specs lean.

Troubleshooting

Issue	Solution
Auth failures	Re-run npm run chrome-debug to confirm storage state is valid; check auth/authSetups/global-setup.ts logs
Flaky selectors	Use "open chrome" workflow to inspect live DOM, then update the page object
Visual drift	Mask dynamic regions before capturing snapshots; use maxDiffPixelRatio: 0.03 as guardrail
Mobile issues	Validate WDIO configs under configs/; ensure LambdaTest credentials are exported
Test failures	Check trace files in test-results/ or run with --debug flag for step-by-step execution

Additional Resources

• Framework Architecture Guide - Deep dive into design patterns and AI workflows
• Playwright Documentation - Official Playwright docs
• WebdriverIO Documentation - Mobile testing with Appium
• Playwright MCP Server - Run the AI-enabled browser control service
• Claude Code - Claude’s IDE with native MCP client support
• OpenAI Codex - Codex developer platform and MCP integrations

License

MIT License - see LICENSE file for details.

Acknowledgments

• Built with Playwright by Microsoft
• AI integration powered by Model Context Protocol (MCP)
• Test app provided by ExpandTesting

---

Happy testing! Keep flows simple, reuse shared helpers, and lean on API calls for reliable setup/teardown.
